This antenna combiner merges the signals from a UHF antenna with a VHF antenna to a single downlead. The PA821B active broadband antenna combiner streamlines the simultaneous operation of many PSM systems at a venue.

#Antenne combiner tv

CNC machined aluminium custom design, lightweight and rugged - fits neatly in any sound bagĤ70-700MHz, 470-608MHz, 470-960MHz, 470-990MHz, 960-1164MHzĤ-pin Push-Pull (Hirose compatible) socket, fused and protected against reverse polarity, 10-18Vdc. Antennas Direct UHF VHF TV Antenna Combiner.

Soft ON-OFF switch for each individual Remote Antenna powering.

Soft ON/OFF switch for each individual Antenna Input LNA.

Intuitive OLED display menu and LED indicators.

User-adjustable system gain at each antenna input.

Built-in band-pass filtering, active combiners and signal splitters.

Four antennas feed up to four diversity receivers.

A green LED indicates power-on status of the system box and the OLED display continuously displays dc input voltage.Īudio Wireless wide tuning range systems are now first choice among freelance sound engineers, hiring companies as well as major broadcasters for all wireless microphone applications. Each dc output port can be individually turned ON/OFF through the OLED menu. The DADM is externally powered between 10-18Vdc, the dc input connector is an industry standard 4-pin Hirose and there are 4 x Hirose dc output connectors available for powering auxiliary equipment. The tuning bandwidth is custom designed with a semi-broadband response to suit varying applications each antenna input gain is individually user adjustable in 1dB steps between +6dB to -10dB, the DADM224-2C is compatible with digital, hybrid and analogue radio microphone receivers available in the industry.

The DADM224-2C has a very high input signal handling capacity with very low noise figure and offers an outstanding inter-modulation performance when compared to other low power devices available.

In applications when remote antenna powering is needed, the DADM224-2C offers individually switchable Remote Antenna powering with RED LEDs indicating power ON/OFF status, the MHA powering can be turned ON/OFF through the OLED display menu. Each antenna input can be individually turned ON/OFF via OLED menu when not used, a LED indicator showing the status of each Antenna input. There are four industry standard BNC input connectors for antenna inputs that enables use of standard low loss RF extension cables, and there 2 x 4 mini-RF SMA connectors feeding the diversity receivers. The DADM224-2C enables the user to cover 2-zone wider area with improved RF reception, the DADM224-2C eliminates multiple receiver antennas and provides a tidy sound bag, cart and trolley set-up applications with improved RF coverage and performance. The DADM224-2C is a 4 IN and 2 x 4 OUT active antenna combiner and distribution system with in-built low loss band-pass filtering, LNA and useradjustable gain stage at each RF input. Designed for where the weight and size matters without sacrificing on performance. Ideal intermodulation characteristic (full band performance +15dBm two-tone test, 3rd order IMMaximum RF input power +20dBm efficiency (100mW).Input Signal Indicator Threshold when input signal >+6dBm.Up to four wireless transmitters can be combined into one transmitting antenna.It operates between 470MHz~960MHz band and connects four Wireless In-ear monitoring transmitters to greatly improve RF performance and reduces chances for signal dropouts.

#Antenne combiner professional

An optional antenna paddle & 32’ TNC cable to the paddle.ĪD-808 is a half-rack size, 4-input, 1-output professional active antenna combiner.Also included will be the parts to rack mount and back to front antenna extension and rack front mounted antenna. Included in this package are Four TNC to BNC adapters. Sennheiser and Shure use the BNC style connection. The Mipro systems use the TNC connectors that screw on. For Mipro MI909 Packages, look under the MI909 page. This page is for Shure & Sennheiser Systems. In addition, any IEM system operating between 470MHz and 960MHz. This IEM Combiner package will work with the Mipro MI909, Shure PSM900, PSM300 and the Sennheiser IEM-G4 In Ear Monitor Systems. Categories: Wireless Solutions, Control Systems, Accessories SKU: WIRACC160 Tag: Wireless Solutions.
